Technical specifications Type 488

入口处的公称直径

DN 25 - DN 100 | 1" - 4"

流道

G - P

實際流道直徑d₀

23 - 92 mm | 0.906 - 3.622 in

实际流道面积A₀

416 - 6648 mm² | 0.644 - 10.304 in²

壓力

0.1 - 16 bar | 1.5 - 232 psig

温度(符合DIN EN标准)

-45 to 250 °C | -49 to 482 °F

阀体 材质

1.4404 | SA 479 316L

阀门连接

Clamps acc. to ASME BPE, DIN 32676, ISO 2852 , Aseptic clamp acc. to DIN 11864 T1 Series A or B (with nut) or DIN 11851, Neumo Sterile thread (with nut), Welded end connection acc. to DIN 11850, Flange acc. to DIN EN 1092 / ASME B 16.5 / DIN 11864 T2 Series A or B, Aseptic flange, Nut flange, Smooth flange, Varlvent connection

波纹管 材质 (可选项al)

EPDM

装载类型

Spring loaded

批准书

PED/ DIN EN ISO 4126-1, PED/ AD 2000-Merkblatt A2, ASME Sec. VIII Div. 1, CRN, AQSIQ, EAC

特价

HyTight Assembly Designed and manufactured acc. to: DIN 11866, ASME BPE, EN 1672-2, DIN ISO 14159, USP class VI and FDA 21 CFR
