Technical specifications Type 449
- Diamètre nominal à Entrée
- DN 25 - DN 100 | 1" - 4"
- Diamètre réel Orifice d₀
- 23 - 92 mm | 0.91 - 3.62 in
- Superficie réelle Orifice A₀
- 416 - 6648 mm² | 0.645 - 10.304 in²
- Pression
- 0.1 - 16 bar | 1.45 - 232 psig
- Température (selon la norme DIN EN)
- -270 to 450 °C | -121 to 392 °F
- Corps Matériau
- Acc. to customer preference all materials available
- Valve Connection
- Flange acc. to DIN EN 1092-1 or acc. to ASME B 16.5
- Soufflet Matériau (optional)
- Stainless steel
- Type de chargement
- Spring loaded
- Approbations
- On request
- Spécial
- Currently no approvals acc. to ASME
