Critical Service Sécurité Valve de lecture type   447

Critical Service

Type 447

Safety valve with full PTFE-lining at the inlet and outlet area for corrosive media

Industries

Approbations

LESER Critical Service safety valves of Type 447 are designed, marked, produced and approved according to the requirements of the following regulations:

  • Approbation LESER CE
  • Approbation de l'ASME LESER
  • Approbation de l'EAC LESER
  • Approbation de LESER China TS

Technical specifications Type 447

Diamètre nominal à Entrée
DN 25 - DN 100 | 1" - 4"
Diamètre réel Orifice d₀
23 - 92 mm | 0.91 - 3.62 in
Superficie réelle Orifice A₀
416 - 6648 mm² | 0.645 - 10.304 in²
Pression
0.1 - 16 bar | 1.45 - 232 psig
Évaluation des brides Entrée
PN 16 | CL150
Température (selon la norme DIN EN)
-85 to 200 °C | -121 to 392 °F
Température (selon la norme ASME)
-29 to 200 °C | -200 to 392 °F
Corps Matériau
1.0406, 10619, 1.0570 + Virgin PTFE | SA 216 WCB
Valve Connection
Flange acc. to DIN EN 1092-1 or acc. to ASME B 16.5
Soufflet Matériau (optional)
PTFE
Type de chargement
Spring loaded
Approbations
PED/ DIN EN ISO 4126-1, PED/ AD 2000-Merkblatt A2, ASME Sec. VIII Div. 1, CRN, AQSIQ, EAC
