Technical specifications Type 526
- Diamètre nominal à Entrée
- DN 25 - DN 200 | 1" - 8"
- Orifice
- D - T
- Diamètre réel Orifice d₀
- 14 - 161.5 mm | 0.551 - 6.36 in
- Superficie réelle Orifice A₀
- 154 - 20485 mm² | 0.239 - 31.75 in²
- Pression
- 0.12 - 413.8 bar | 2 - 6000 psig
- Évaluation des brides Entrée
- CL150 - CL2500
- Température (selon la norme DIN EN)
- -270 to 550 °C | -454 to 1022 °F
- Température (selon la norme ASME)
- -268 to 538 °C | -450 to 1000 °F
- Corps Matériau
- 1.0619, 1.4408, 1.7357 | SA 216 WCB, SA 351 CF8M, SA 217 WC6, SA 352 LCB, SA 351 CF3M, SA 995 Gr 4A CD3MN (Duplex), SA 494 M35-1 (Monel), SA 494 CX2MW (Hastelloy), SA 494 CW-6MC (Inconel)
- Valve Connection
- Flange acc. to ASME B 16.5 or acc. to DIN EN 1092-1 or acc. to JIS 2220
- Soufflet Matériau (optional)
- INCONEL® 625
- Type de chargement
- Spring loaded
- Approbations
- ASME Sec. VIII Div. 1, DGRL/DIN EN ISO 4126-1, DGRL/AD 2000-Merkblatt A2, AQSIQ, EAC
- Sociétés de classification
- LR, RINA, DNV GL, BV, ABS, KR
